Mini Sas Cable Pinout

Buses and slots pinouts.

Mini sas cable pinout.

The te mini sas product family is a high speed multi lane interconnect for both internal and external solutions including both receptales and cable assemblies. The low profile system provides 4x and 8x cable plug options and the external i o connectors includes eight sideband signals per 4x port. It carries the equivalent of four sata sas 7 pin connections through a sff 8087 to sff 8087 cable providing 12gbps of throughput using sas or sata ii 3 0gbps devices. The pinouts for the 36 pin sff 8643 internal hd mini sas plug connector are.

Typical application of sff 8643 connector is a internal sas link between a sas hba to sas drives. Copper cable assembly perfect for internal ipass minisas sff 8087 to 4 sata with sideband applications also available in 64 54 44 34cm with sideband 70cm. The interfaces are adopted for the sas 2 1 sas 3 and pcie standards. The system is designed to be compliant to sff 8086 8087 and 8088 standards and supports sas 2 0 applications.

The pinout follows the sff 9402 specificatons. The sas8087s4r50 sff 8087 to 4x sata reverse cable features one 36 pin plug sff 8087 which fans out to four sata 7 pin receptacles providing a reliable solution for connecting a mini sas backplane to a sas sata raid controller or motherboard. Some storage controllers may include sas interface and nvme pcie interface by multiplexing the data and sidebands signals. The sff 8087 connector is a very widely used connector type that is commonly used today on sas cards.

This is the 36 pin sff 8643 internal hd mini sas plug connector. Sas is a serial point to point interfce with scsi protocol set. Mini sas hd sff 8643 pinout.
